1.Application (LiYCY cable):
LiYCY cable can be used for signal transmission between electronic devices, in computer systems or process control units with increased electromagnetic compatibility requirements.
 |
 |
 |
 |
2.Standards (LiYCY cable):
IEC 60332, BS5308
3.Cable Drawing (LiYCY cable):
 |
 |
4.Cable Construction (LiYCY cable):
|
Item |
LiYCY TCWB Screened Cable |
|
Conductor |
Class 5 flexible copper |
|
Insulation |
PVC |
|
Screen |
Tinned Copper Wires Braid |
|
Outer Sheath |
PVC |
|
Nominal Voltage |
U0/U: 250/250V |
|
Test voltage |
1200 V |
|
Temperature Range |
Fixed: -30°C to +80°C |
|
Color |
Optional |
|
Certification |
CE |
5.Cable Specification (LiYCY cable):
|
Specification |
Outer diameter |
Copper index |
Weight |
|
2 x 0.14 |
3.9 |
12 |
20 |
|
3 x 0.14 |
4.1 |
13 |
28 |
|
4 x 0.14 |
4.3 |
14.3 |
33 |
|
5 x 0.14 |
4.6 |
15.5 |
38 |
|
6 x 0.14 |
4.9 |
18.2 |
38 |
|
7 x 0.14 |
4.9 |
19 |
49 |
|
8 x 0.14 |
5.8 |
21.2 |
56 |
|
10 x 0.14 |
6.1 |
28.5 |
66 |
|
12 x 0.14 |
6.3 |
30.4 |
78 |
|
14 x 0.14 |
6.7 |
32 |
80 |
|
15 x 0.14 |
6.9 |
37.8 |
86 |
|
16 x 0.14 |
7 |
43 |
90 |
|
18 x 0.14 |
7.3 |
48.8 |
95 |
|
20 x 0.14 |
7.7 |
53.9 |
100 |
|
21 x 0.14 |
7.9 |
55.5 |
105 |
|
24 x 0.14 |
8.3 |
61 |
112 |
|
25 x 0.14 |
8.5 |
63 |
120 |
|
28 x 0.14 |
8.5 |
66.1 |
141 |
|
30 x 0.14 |
8.7 |
69 |
155 |
|
36 x 0.14 |
9.3 |
83 |
170 |
|
40 x 0.14 |
10.4 |
87.5 |
178 |
|
44 x 0.14 |
10.7 |
110.5 |
185 |
|
50 x 0.14 |
11.1 |
122.5 |
195 |
|
2 x 0.25 |
4.5 |
16 |
32 |
|
3 x 0.25 |
4.7 |
21 |
37 |
|
4 x 0.25 |
5 |
24 |
41.3 |
|
5 x 0.25 |
5.6 |
29 |
51.2 |
|
6 x 0.25 |
6 |
30 |
58 |
|
7 x 0.25 |
6 |
37 |
65 |
|
8 x 0.25 |
7.1 |
42 |
73 |
|
10 x 0.25 |
7.5 |
46 |
82 |
|
12 x 0.25 |
7.7 |
53 |
98 |
|
14 x 0.25 |
8 |
59 |
99 |
|
15 x 0.25 |
8.3 |
61 |
111 |
|
16 x 0.25 |
8.4 |
64 |
119 |
|
18 x 0.25 |
8.8 |
83 |
125 |
|
20 x 0.25 |
9.3 |
88 |
136 |
|
21 x 0.25 |
9.6 |
93 |
161 |
|
25 x 0.25 |
10.7 |
114 |
172 |
|
28 x 0.25 |
10.8 |
126 |
181.1 |
|
32 x 0.25 |
11.4 |
138 |
203 |
|
36 x 0.25 |
11.8 |
148 |
220 |
|
40 x 0.25 |
12.7 |
157 |
248 |
|
50 x 0.25 |
13.8 |
178 |
318 |
|
61 x 0.25 |
15 |
205 |
365.2 |
|
2 x 0.34 |
4.9 |
21 |
37 |
|
3 x 0.34 |
5.1 |
27 |
42 |
|
4 x 0.34 |
5.7 |
28 |
52 |
|
5 x 0.34 |
6.2 |
30 |
60 |
|
6 x 0.34 |
6.8 |
45 |
64 |
|
7 x 0.34 |
6.8 |
48 |
75 |
|
8 x 0.34 |
7.8 |
52 |
94 |
|
10 x 0.34 |
8.3 |
74 |
105 |
|
12 x 0.34 |
8.5 |
80 |
123 |
|
14 x 0.34 |
8.9 |
86 |
154 |
|
15 x 0.34 |
9.2 |
90 |
155 |
|
16 x 0.34 |
9.4 |
94 |
160 |
|
18 x 0.34 |
10.2 |
103 |
173 |
|
20 x 0.34 |
10.7 |
112 |
192 |
|
21 x 0.34 |
11.1 |
116 |
199.2 |
|
25 x 0.34 |
11.9 |
135 |
259 |
|
28 x 0.34 |
12 |
153 |
280 |
|
30 x 0.34 |
12.3 |
159 |
291.1 |
|
32 x 0.34 |
13 |
165 |
305 |
|
36 x 0.34 |
13.4 |
179 |
331 |
|
40 x 0.34 |
14.8 |
200 |
365 |
|
50 x 0.34 |
15.9 |
235 |
431 |
|
2 x 0.5 |
5.6 |
29 |
47 |
|
3 x 0.5 |
5.9 |
38 |
55 |
|
4 x 0.5 |
6.3 |
43 |
70 |
|
5 x 0.5 |
7 |
51 |
90 |
|
6 x 0.5 |
7.6 |
59 |
104 |
|
7 x 0.5 |
7.6 |
65 |
112 |
|
8 x 0.5 |
8.7 |
70 |
120 |
|
10 x 0.5 |
9.3 |
88 |
139 |
|
12 x 0.5 |
9.6 |
99 |
177 |
|
18 x 0.5 |
11.8 |
134 |
239 |
|
20 x 0.5 |
12.1 |
149 |
276 |
|
25 x 0.5 |
13.7 |
211 |
352 |
|
30 x 0.5 |
14.5 |
230 |
397 |
|
2 x 0.75 |
6 |
38 |
53 |
|
3 x 0.75 |
6.3 |
49 |
65 |
|
4 x 0.75 |
7 |
58 |
79 |
|
5 x 0.75 |
7.6 |
67 |
109 |
|
7 x 0.75 |
8.2 |
100 |
156 |
|
10 x 0.75 |
10.5 |
130 |
187 |
|
12 x 0.75 |
10.8 |
154 |
218 |
|
18 x 0.75 |
13 |
195 |
327 |
|
25 x 0.75 |
15.3 |
280 |
454 |
|
30 x 0.75 |
15.8 |
312 |
486 |
|
2 x 1.0 |
6.3 |
43 |
72 |
|
3 x 1.0 |
6.8 |
56 |
90 |
|
4 x 1.0 |
7.3 |
68 |
109 |
|
5 x 1.0 |
8 |
79 |
126 |
|
7 x 1.0 |
8.6 |
118 |
171 |
|
10 x 1.0 |
11.1 |
140 |
228 |
|
12 x 1.0 |
11.4 |
168 |
259 |
|
18 x 1.0 |
13.4 |
252 |
389 |
|
25 x 1.0 |
16.2 |
335 |
517 |
|
2 x 1.5 |
7.1 |
58 |
90 |
|
3 x 1.5 |
7.5 |
74 |
115 |
|
4 x 1.5 |
8.1 |
108 |
129 |
|
5 x 1.5 |
8.8 |
129 |
176 |
|
7 x 1.5 |
9.5 |
164 |
220 |
|
12 x 1.5 |
12.7 |
254 |
376 |
|
18 x 1.5 |
15.3 |
350 |
519 |
|
25 x 1.5 |
17.9 |
550 |
901 |
6.Production Progress
7.Certificates:
 |
 |
8.Packing:
-Steel wooden drum (fumigation)
Cable length in each drum: 1000m/2000m or as per actual cable length requirements.
-Drum size:
As per cable length and container size
In order to quote you accurate price, kindly tell us your needed cable length quantity. Larger quantity, more discount benefit ready for you!
-Shipping Port:
Qingdao, or other ports as per your requireents.
-Sea freight:
FOB/C&F/CIF quotation are all available.
 |
 |
 |
