1.Application
These cables are designed to provide high flexibility and have the capacity to withstand weather, oils/greases, mechanical and thermal stresses.
Applications include handling equipment, mobile power supplies, worksites, stage and audio visual equipment, port areas and dams. Also for use in drainage and water treatment, cold environments and severe industrial environments.
2.Standards
IEC60245, GB/T 5013,JB/T8735.
Customized Other Standard such as VDE,ASTM,DIN according to the customer's request .
3.Technical Data
Conductor
Class 5 flexible plain copper
Insulation
EPR (Ethylene Propylene Rubber)
Sheath
PCP (Polychloroprene)
Sheath Colour
Black
Voltage Rating
450/750V
Temperature Rating
Conductor operating temperature
-30°C to +60°C (85°C max)
Minimum Bending Radius
Up to 25mm2: 6 x overall diameter
Above 25mm2: 8 x overall diameter
Core Identification
2 Cores: Blue, Brown
3 Cores: Green/Yellow, Blue, Brown
4 Cores: Green/Yellow, Brown, Black, Grey
5 Cores: Green/Yellow, Blue, Brown, Black, Grey
6 Cores and above: Black with White numerals, Green/Yellow
4.Specification details:
H07RN-F Single Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size | Stranding | Nominal Overall Diameter | Nominal Overall Diameter | Approx. Weight |
1x1.5 | 30x0.25 | 0.8 | 6.0 | 49 |
1x 2.5 | 50x0.25 | 0.9 | 6.6 | 63 |
1x4 | 56x0.30 | 1.0 | 7.6 | 92 |
1x6 | 84x0.30 | 1.0 | 8.3 | 115 |
1x10 | 80x0.40 | 1.2 | 10.7 | 189 |
1x16 | 126x0.40 | 1.2 | 12.0 | 260 |
1x25 | 196x0.40 | 1.4 | 14.1 | 369 |
1x35 | 276x0.40 | 1.4 | 15.8 | 500 |
1x50 | 396x0.40 | 1.6 | 18.3 | 689 |
1x70 | 360x0.50 | 1.6 | 20.7 | 918 |
1x95 | 475x0.50 | 1.8 | 23.4 | 1202 |
1x120 | 608x0.50 | 1.8 | 25.6 | 1489 |
1x150 | 756x0.50 | 2.0 | 28.3 | 1824 |
1x185 | 925x0.50 | 2.2 | 31.0 | 2202 |
1x240 | 1221x0.50 | 2.4 | 34.5 | 2847 |
1x300 | 1525x0.50 | 2.6 | 37.7 | 3495 |
1x400 | 2013x0.50 | 2.8 | 37.7 | 3495 |
1x500 | 1769x0.60 | 3.0 | 37.7 | 3495 |
1x630 | 2257x0.60 | 3.0 | 37.7 | 3495 |
H07RN-F 2 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size | Stranding | Nominal Overall Diameter | Nominal Overall Diameter | Approx. Weight |
2 X 1.0 | 32/0.20 | 0.8 | 8.4 | 98 |
2 X 1.5 | 30/0.50 | 0.8 | 9.4 | 116 |
2 X 2.5 | 50/0.25 | 0.9 | 11 | 164 |
2 X 4.0 | 56/0.30 | 1.0 | 12.8 | 232 |
2 X 6.0 | 84/0.30 | 1.0 | 14.2 | 297 |
2 X 10.0 | 80/0.40 | 1.2 | 20.4 | 573 |
2 X 16.0 | 126/0.40 | 1.2 | 23 | 774 |
2 X 25.0 | 196/0.40 | 1.4 | 27.4 | 1110 |
2 X 35.0 | 276/0.40 | 1.4 | 30.8 | 1474 |
H07RN-F 3 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size | Stranding | Nominal Overall Diameter | Nominal Overall Diameter | Approx. Weight |
3 X 1.0 | 32/0.20 | 0.8 | 9.0 | 108 |
3 X 1.5 | 30/0.50 | 0.8 | 10.3 | 141 |
3 X 2.5 | 50/0.25 | 0.9 | 11.8 | 200 |
3 X 4.0 | 56/0.30 | 1.0 | 13.7 | 285 |
3 X 6.0 | 84/0.30 | 1.0 | 15.2 | 371 |
3 X 10.0 | 80/0.40 | 1.2 | 21.9 | 712 |
3 X 16.0 | 126/0.40 | 1.2 | 24.7 | 971 |
3 X 25.0 | 196/0.40 | 1.4 | 29.4 | 1394 |
H07RN-F 4 Core Type 450/750V EPR/PCP Trailing Rubber Cable
Core and Size | Stranding | Nominal Overall Diameter | Nominal Overall Diameter | Approx. Weight |
4 X 1.0 | 32/0.20 | 0.8 | 10.0 | 134 |
4 X 1.5 | 30/0.25 | 0.8 | 11.2 | 174 |
4 X 2.5 | 50/0.25 | 0.9 | 12.6 | 249 |
4 X 4.0 | 56/0.30 | 1.0 | 15.1 | 361 |
4 X 6.0 | 84/0.30 | 1.0 | 16.9 | 480 |
4 X 10.0 | 80/0.40 | 1.2 | 24 | 890 |
4 X 16.0 | 126/0.40 | 1.2 | 27 | 1225 |
4 X 25.0 | 196/0.40 | 1.4 | 32.6 | 1792 |
4 X 35.0 | 276/0.4 | 1.4 | 36.5 | 2380 |
4 X 50.0 | 396/0.4 | 1.6 | 42 | 3635 |
4 X 70.0 | 360/0.5 | 1.6 | 49 | 4830 |
4 X 95.0 | 475/0.5 | 1.8 | 55 | 6320 |
